PESO Approval for Furnace Oil: Storage Tank Guide

• PESO Approval for Furnace Oil governs the safe storage and handling of furnace oil within the Indian petroleum safety regime.
• Furnace oil falls within Petroleum Class C, and the relevant PESO requirement will depend upon quantity stored, installation type and activity.
• Tank manufacturers and/or importers must make sure that tank designs, drawings and installations comply with the relevant PESO requirements.

---

Introduction

Recently, a furnace oil equipment manufacturing firm approached the compliance team for a seemingly simple question: “We have designed the storage tank. May we manufacture the tank and deliver it to our client?”

The challenge came from the fact that their client was planning to use this tank for bulk storage of furnace oil. Their tank design had been completed. But the regulatory angle had not been checked yet. The capacity, layout, and the petroleum class had to be considered first.

It’s a very common problem in petroleum equipment projects.

PESO Approval for Furnace Oil is not just an approval attached to the tank. The regulation depends on the kind of petroleum product, quantity, storage arrangements, installation, and operations. Furnace Oil (FO) comes under the category of Petroleum Class C as per PESO.

For the manufacturer/importer, this difference is important because the manufacturer would be concerned about the equipment portion of the installation, whereas the user would need a license for the actual installation of the petroleum storage facility.

The best solution is to establish which PESO process is involved prior to the manufacture/installation of the tank.

---

What Is PESO Approval for Furnace Oil?

PESO Approval for Furnace Oil refers to the applicable regulatory approval, permission or licence for the storage and handling of furnace oil under the Petroleum Rules, 2002.

PESO (Petroleum and Explosives Safety Organisation) is the government organisation responsible for administering important safety requirements relating to petroleum, explosives, compressed gases and other hazardous substances in India. For petroleum installations, PESO oversees applicable requirements for safe storage, handling and related licensing.

Furnace Oil (FO) is classified by PESO as Petroleum Class C. Therefore, its storage is subject to specific requirements depending on the quantity stored and the type of installation.

For a furnace-oil storage tank manufacturer or importer, PESO compliance should be considered before the tank is manufactured or supplied. The requirement can depend on factors such as:

• Furnace oil storage capacity
• Number and type of tanks
• Bulk or non-bulk storage
• Proposed installation location
• Tank and piping arrangement
• Connected pumps and equipment
• Applicable PESO approval or licence

It is also important to distinguish between tank compliance and approval of the complete storage installation. A technically compliant tank does not automatically give the customer permission to store furnace oil at a particular site.

Therefore, the applicable PESO requirements should be established during the design stage so that the tank, drawings and supporting technical documents are prepared according to the actual storage application.

---

Is PESO Approval Required for Furnace Oil Storage?

Yes, there can be PESO requirements in relation to furnace-oil storage but these will vary depending on the volume and installation.

PESO’s FAQ clearly mentions that there is no license required for storing or transporting Furnace Oil/LDO where the volume is not more than 45,000 liters in bulk. However, in case the volume of class C petroleum storage is more than 5,000 liters, then reporting/permission becomes significant under Rule 140 of the Petroleum Rules 2002.

The revised PESO FAQ states that there is no need for a license for Class C petroleum storage up to 45,000 liters but one-time permission from the concerned PESO office is still essential under Petroleum Rules.

It is an important point for any business organization.

Any manufacturer should not claim that the furnace oil tank is PESO approved merely because it has been made based on engineering drawing. The regulatory issue should be taken into consideration with regard to the petroleum installation.

---

Furnace Oil Classification Under Petroleum Rules

Furnace oil is relevant to PESO because it falls within the petroleum regulatory framework.

PESO’s published requirement document explains the classification of petroleum based on flash point:

Petroleum Class	Flash Point
Class A	Below 23°C
Class B	23°C and above but below 65°C
Class C	65°C and above but below 93°C

The example of PESO clearly shows that FO is one of the petroleum products included under the licensing regime Such classification determines the safe handling of this product.

In case the product is to be stored in the tank, the classification dictates that product specification is determined at the initial stage. The name of the product such as furnace oil does not suffice for that purpose.

---

What Does PESO Check for a Furnace Oil Storage Tank?

However, there is not one checklist that can be used indiscriminately in all cases of furnace oil tanks The regulatory analysis will depend on how the system was installed. Nevertheless, several technical considerations will normally have to be addressed.

Furnace Oil Tank Capacity

The capacity will be one of the first parameters that need to be set Information concerning the capacity should be consistent across tank drawings, datasheets, applications, and site plans.

For instance, when the tank drawing shows one capacity while the site plan indicates another capacity, this can lead to unnecessary complications in the regulatory process.

In the case of multiple tanks, note:

• Number of tanks
• Capacity of individual tanks
• Total capacity
• Product stored in each tank
• Tank identification
• Existing and proposed capacities
• The capacity must never be an afterthought.
• Design and Construction Considerations

The design and construction details of a furnace-oil storage tank may need extensive technical data in order to show that the equipment to be used is suited for the task.

This may entail:

• Tank dimensions
• Material specifications
• Shell and bottom details
• Roof arrangement
• Design calculations
• Nozzle details
• Inlet and outlet connections
• Vent arrangement
• Drain arrangement
• Level indication
• Temperature-related provisions where applicable
• Valves and fittings
• Inspection and testing records

The exact requirements should be determined from the applicable rules and the particular installation.

Furnace Oil Tank Drawings

The drawings are especially crucial since it links the engineering design with the application The right drawing must convey what really is being erected.

Common drawings may include:

• Fabrication drawing of tank
• General arrangement drawing
• Site arrangement
• Pipe arrangement
• Equipment arrangement
• Foundation details
• Fire protection arrangement
• Access and safety arrangement

It is quite common for one to attach an old drawing of some other project simply on the basis that the tank looks alike It may lead to difficulties.

A tank which is suitable for one location may not suit another because of varying surrounding distances and pipe/equipment arrangements.

---

PESO Requirements for Furnace Oil Storage Tanks

The storage tank is just one aspect of the issue of compliance.

A fuel-oil system could consist of:

Tank → receiving pipe → pump → pipeline → heating/filtration system → furnace or processing equipment

All these components may affect the general safety evaluation.

Site Layout

The site layout must be a true representation of the proposed system.

This will depend on:

• Furnace oil tanks
• Pump house
• Transfer pipelines
• Filling/unloading area
• Access roads
• Buildings
• Boundary wall
• Fire-fighting equipment
• Drainage arrangements
• Electrical installations
• Emergency access
• Other nearby installations

The objective is to demonstrate how the petroleum installation sits within the premises.

Fire Safety

Petroleum storage facilities need suitable measures of fire prevention.

There are precautions against fire in the Petroleum Rules and include restrictions on smoking and ignitions in petroleum installations and storage facilities The actual fire safety measures would be developed based on the installation and not the checklist.

Piping and Transfer System

Furnace oil is required to be transferred from the reception point to the storage tank and then to the consuming facility.

This means that the following should be considered when developing the system:

• Product transfer piping
• Valves
• Connections
• Pumps
• Isolation facilities
• Drain facilities
• Preventing leaks
• Safe access
• Emergency shut down facilities as required
• The tank can not be evaluated alone as it is part of the petroleum installation.

---

Documents Required for PESO Approval for Furnace Oil

Documentation is one of the areas where otherwise technically sound projects can lose time.

For furnace-oil storage projects, the exact documents depend on the applicable approval or licence route. However, a compliance file may involve the following categories.

Company Documents

These may include:

• Certificate of incorporation
• PAN
• Company address
• Authorisation letter
• Authorised signatory details
• Applicant information

Land and Site Documents

Depending on the project, documents may include:

• Ownership proof
• Lease documents
• Possession documents
• Site plan
• Location details
• Applicable NOC documents

Technical Documents

These can include:

• Furnace oil tank drawings
• Tank specifications
• Capacity details
• Material specifications
• Site layout
• Piping drawings
• Pump details
• Safety system details
• Fire protection arrangements
• Testing documentation
• Manufacturer documents

The exact documentation should be confirmed against the applicable PESO application category.

---

Which PESO Form Applies to Furnace Oil Storage?

• This is when caution must be exercised.
• PESO application forms categorize petroleum operations into different types.
• For instance, Form IX is one of the application forms listed by PESO for granting, amending, renewing or transferring license to import and store petroleum.
• Form XV is the current form according to PESO SOP that applies to importing and storing of petroleum in an installation.
• Form XVI on the other hand applies for the storage of some petroleum products not in bulk but at varying quantities according to the product.
• This means picking any form from an old checklist cannot be recommended.
• This is because there are different procedures, products and installations that should be considered.

---

PESO Approval for Furnace Oil: Application Process

The practical procedure can be broken down into the following steps.

Step 1: Identification of the Product

Ensure that the product to be stored is furnace oil and identify the type of petroleum and Do not assume that you start with the tank drawing only.

Step 2: Determine the Amount of Storage

Identify:

• Storage Capacity per Tank
• Total storage capacity
• Number of Tanks
• Existing storage
• Proposed additional storage

This will help in determining the regulatory route to take.

Step 3: Installation Review

Understand how the tank will work Inspect the receiving, pumping, piping, process/equipment associated with the tank and the safety considerations.

Step 4: Drawing Preparation

Draw the drawings based on the real project, not based on any templates Tank drawings should match the site layout.

Step 5: Determine PESO Route of Approvals

Identify if the installation requires:

• Approval before installation
• One-time approval
• Petroleum Storage License
• Amendment of existing approval
• Renewal
• Other Regulatory Permission

SOP of PESO provides the current framework for Petroleum Approvals and Licenses.

Step 6: Prepare the Application File

Prepare the file containing all information about the applicant, the site, the tank, the engineering and the safety documentation Cross-check the capacity, name, address and drawing references at this stage.

Step 7: Submission Through the Applicable Portal

According to the newly issued FAQ by PESO, applicants must first register on the National Single Window System (NSWS) and then move on to the PESO Petroleum Service portal, upload the necessary documents and pay the required fee.

Step 8: Answering Regulatory Questions

If any questions are posed by the regulatory authority, answer them based on the engineering documentation Do not make individual changes In case the capacity of the tank is changed in one document, it should be checked if it is mentioned in other parts of the application.

Step 9: Inspection or Verification

Depending on the situation, an inspection or verification might be performed The physical tank and installation must correspond to the approved drawings.

Step 10: Compliance Maintenance

Once the tank installation gets approved, the operator should maintain the compliance.

---

Can a Manufacturer Get PESO Approval for a Furnace Oil Storage Tank?

A furnace-oil storage tank manufacturer can support PESO compliance, but the approval of the tank and the approval or licence for the petroleum storage installation are not necessarily the same thing.

For the manufacturer, the focus is on the tank’s design, fabrication, technical specifications, drawings and applicable compliance requirements. The customer, on the other hand, is responsible for meeting the requirements applicable to the actual site where furnace oil will be stored.

This distinction is important when a manufacturer supplies tanks to different industrial customers. A tank may be technically suitable for furnace-oil storage, but that does not automatically mean the customer’s entire storage facility is licensed by PESO.

Therefore, manufacturers should clearly identify the scope of any PESO approval, recognition or compliance documentation associated with their equipment. Customers should separately confirm the approval or licensing requirements applicable to their proposed storage installation.

For businesses manufacturing or importing furnace-oil storage tanks, checking the regulatory position before fabrication can prevent costly design changes and confusion during the customer’s PESO approval process.

---

What Should Furnace Oil Tank Manufacturers Prepare Before Fabrication?

For manufacturers and importers, regulatory planning should start before production.

A practical technical file can include:

Product Information

• Furnace oil description
• Product classification
• Flash point information
• Intended storage conditions
• Customer application

Tank Information

• Tank capacity
• Dimensions
• Materials
• Design details
• Fittings
• Nozzles
• Venting arrangement
• Inspection points

Installation Information

• Site layout
• Tank location
• Foundation
• Transfer piping
• Pump arrangement
• Fire safety provisions
• Access arrangements

Compliance Information

• Applicable PESO rule
• Relevant application form
• Test reports
• Inspection documents
• Approval correspondence
• Approved drawings

Maintaining this file from the beginning makes future customer projects considerably easier.

---

Common Mistakes in Furnace Oil PESO Applications

Treating the Tank as the Entire Project

The tank is important, but the regulator may need to consider the entire installation.

Using an Incorrect Petroleum Classification

Do not classify a product based only on its trade name and Use reliable product specifications.

Preparing Drawings After Fabrication

This is risky If the finished tank or installation does not match the regulatory requirements, correcting it can be expensive.

Copying Another Project’s Layout

A similar tank does not mean a similar site The surrounding buildings, access, pipelines and safety arrangements can be different.

Inconsistent Capacity

One document may say 50 KL while another says 48 KL These discrepancies should be resolved before filing.

Assuming a Factory Licence Replaces PESO Compliance

A general factory or industrial approval does not automatically replace petroleum-specific regulatory requirements.

Ignoring Existing Tanks

If a new furnace-oil tank is added to an existing petroleum installation, the additional tank should be assessed in the context of the existing facility.

---

Furnace Oil Storage Tank Safety Considerations

Safety should be considered from the first engineering drawing.

Key areas include:

• Tank integrity
• Leakage prevention
• Safe transfer connections
• Proper valves
• Controlled filling
• Venting
• Fire prevention
• Ignition-source control
• Emergency access
• Spill management
• Electrical safety
• Inspection and maintenance

The Petroleum Rules specifically contain fire-prevention provisions for petroleum storage installations.

For a manufacturer, the important lesson is straightforward do not design the tank first and ask the compliance question later Regulatory requirements should influence the engineering decision from the beginning.

---

What Is the Cost of PESO Approval for Furnace Oil?

There is no single fixed cost for every furnace-oil storage project.

The overall compliance expense can vary according to:

• Storage capacity
• Number of tanks
• Installation configuration
• Engineering drawings
• Testing requirements
• Site modifications
• Government fees
• Inspection requirements
• Documentation
• Existing facility conditions
• Consultancy requirements

Government fees and project-specific engineering costs should therefore be considered separately.

For an importer, additional costs may arise where imported equipment documentation does not sufficiently match Indian regulatory requirements For a manufacturer, the bigger commercial risk can actually be the cost of redesigning or modifying equipment after fabrication.

---

How Diligence Certification Supports Furnace Oil Tank Compliance

For furnace-oil storage tank manufacturers and importers, PESO compliance involves more than submitting an application. The tank design, capacity, technical specifications, drawings and proposed installation must be consistent with the applicable requirements.

Diligence Certification can help review the proposed tank and identify the applicable PESO route, check technical and site documents, coordinate drawings and prepare the application file. We can also support responses to regulatory queries and inspection-related requirements where applicable.

For imported tanks, we can review overseas technical documents and identify gaps before submission, helping avoid delays caused by inconsistent specifications or incomplete documentation.

---

Conclusion

PESO Approval for Furnace Oil should be treated as part of the complete petroleum storage compliance process, not as a label attached to a storage tank.

For furnace-oil tank manufacturers and importers, the first task is to understand the distinction between manufacturing the tank and licensing or approving the customer’s petroleum storage installation. Furnace oil falls under Petroleum Class C, and PESO’s current guidance sets different requirements according to storage quantity and installation conditions.

The best time to address compliance is before fabrication. Once a tank has been manufactured, transported and installed, correcting an unsuitable design or incomplete documentation can become expensive.

If you are manufacturing, importing or supplying furnace oil storage tanks, Diligence Certification can assist with applicability assessment, technical documentation, PESO application preparation and regulatory coordination.

---

Frequently Asked Questions
