PESO Approval for Naphtha Storage: Documents, Process & Compliance Guide

• PESO Approval for Naphtha Storage is important due to the fact that naphtha is one of the petroleum products regulated under the Petroleum Rules, 2002 and is therefore required to be in compliance with the relevant licensing.
• The approval procedures for importers depend upon the equipment, installation and petroleum storage activity; proper drawings, specifications, certificates and application are very important.
• Diligence Certification could help in applicability assessments, documentation, technical coordination, application preparation and PESO inquiries.

---

Introduction

One such case involved a petroleum equipment importer who consulted with the compliance group after having already picked out the equipment from an overseas manufacturer. Although the equipment was found to be technically compatible with the job at hand, the compliance audit revealed that there was a problem with the equipment documentation; the documentation was not done with reference to the Indian submission.

The overseas manufacturer had the drawings. The importer had the invoices and technical literature. What was missing was a compliance package tying together the equipment documentation and the Indian installation This is important in connection with PESO Approval for Naphtha Storage.

Naphtha is explicitly mentioned in the list of petroleum products which require a licence to store as per the Petroleum Rules, 2002. These rules govern the import, transportation, storage, production, processing, and blending of petroleum, and the requisite approval will depend upon the product category, amount, installation, and nature of the activity Thus, in case of a petroleum manufacturer/importer, instead of asking themselves “do we have the tank certificate?”, the question should be.

Does the entire imported apparatus and the proposed storage facility meet all the PESO requirements This guide focuses on that practical issue.

---

What Is PESO License for Naphtha Storage?

PESO License for Naphtha Storage is the relevant regulation required for naphtha storage in India under the Petroleum Rules, 2002. PESO means Petroleum and Explosives Safety Organisation and comes under the purview of the Department for Promotion of Industry and Internal Trade (DPIIT), Ministry of Commerce and Industry, Government of India.

As far as importers are concerned, it is noteworthy to say that licensing for storage and approval of equipment are two separate issues. A naphtha storage project can have tanks, pumps, valves, piping, instruments and hazardous area electrical equipment, each of which requires specific attention.

Thus, it will be wise to consider PESO regulations even before the equipment is shipped to India. This way it would be possible to review the drawings, certificates and installation plan during the procurement stage.

Is naphtha covered under PESO licensing requirements?

Yes. The PESO published list explicitly mentions that naphtha is among the petroleum products that require licensing for storage under the Petroleum Rules, 2002.

The classification of naphtha should, however, be determined based on its physical properties and relevant regulatory documents rather than being inferred from the generic product name.

This is why a project needs to commence with an applicability assessment.

---

Why Is PESO Approval Important for Naphtha Storage?

Naphtha storage is hazardous because of the fire and vapor hazards associated with it. The regulations applicable to petroleum products depend upon certain attributes such as flash point.

According to the Petroleum Rules, 2002, petroleum products have been classified into Class A, Class B, and Class C on the basis of their flash point. Under the current SOP of PESO, Class A is defined as petroleum products with a flash point less than 23°C, Class B as 23°C and above but less than 65°C and Class C as 65°C and above but less than 93°C.

Such classification has implications for the regulatory aspects of storage.

From the point of view of the importer, compliance not only ensures regulation but also avoids one of the most common commercial problems. This problem is that of equipment reaching Indian sites without its documentation being completed After fabrication overseas, changing the nozzle location, tank connections, valve configurations or hazardous area specifications becomes costly. It is cheaper to detect any such change while the design package is reviewed.

---

PESO Approval for Naphtha Storage: What Importers Need to Know

As far as the importer is concerned, the need for PESO certification usually becomes relevant once the equipment is sourced from abroad and the Indian regulations are considered for compliance. While the tank may be technically suitable for storage of naphtha, this does not mean that the whole installation will comply with the PESO regulations.

First, the importer should examine the whole installation and not only the major tank. The installation might consist of the storage tanks, pumps, valves, pipelines, instrumentation, fittings and electrical equipment used in hazardous areas.

In the first place, the importer should determine the type of the naphtha stored, the volume and the storage method used. Such information will be helpful to define the type of the petroleum and its corresponding licensing procedures.

Next, the importer should inspect the equipment supplied from abroad. In such a case, model numbers, capacity, material used, design data, drawings, certificates and test reports should be evaluated before making the final decision on the equipment. Also, if any hazardous-area electrical equipment is provided with the imported installation, its PESO regulations should be considered separately The conditions of the site are equally crucial. The tank configuration, pipe placement, safety measures, and other installation aspects must match the equipment that is to be imported Practically,

the PESO approval of Naphtha storage should be sought even before the procurement process is completed. Checking for regulatory requirements during the design phase makes it much simpler to rectify any documents or specifications compared to doing so once the equipment arrives in India.

---

What Documents Are Required for PESO Approval?

There cannot be any realistic document checklist that can suit all naphtha facilities. The documents will vary based on the specific approval process and project design.

Nevertheless, there are various types of documents that an importer ought to be ready to produce.

Documents from Company and Applicant

Common documents would include:

• Company incorporation/registration documents
• Applicant information
• Authorization documents
• Importing company details
• Details of Indian agent, wherever relevant
• Details of Manufacturer
• Manufacturer’s authorization
• Contact details of technical personnel responsible

The applicant information should be consistent in Forms, Declarations, Manufacturer Documents & Technical Certificates.

Product/Equipment Documentation

The equipment documentation could include:

Engineering Drawings

Drawing is especially crucial in the case of a storage project.

Based on the application, it will contain:

• Site layout
• Tank layout
• General arrangement drawing
• Piping and instrumentation diagram
• Equipment arrangement
• Transfer piping
• Valve arrangement
• Pump arrangement
• Fire protection arrangement
• Drainage arrangement
• Safety equipment arrangement
• Details about hazardous area
• Access and approach arrangement
• The drawing needs to depict the actual proposed installation.
• An old drawing that is copied from some other plant is not an easy route out.It could be an unnecessary question if the submitted drawing does not match the existing site.

---

What Is the PESO Application Process for Naphtha Storage?

The process of PESO Approval for Naphtha Storage is a technical compliance process, not merely a filling of an online form. In the case of importers, coordinating documents ahead of time will save from unnecessary questions and delays.

Step 1: Identifying Applicability

Firstly, look at the naphtha specification, storage volume, suggested tank, installation location, and imported equipment. Identify the applicable petroleum classification, storage method and approval process, then select the application form.

Step 2: Checking Imported Equipment

Get the entire technical package from the foreign equipment manufacturer. Ensure the information about manufacturer, model number, capacity, material, design specifications, operating temperature and pressure, certifications, test results and relevant standards are included in all documents. All documents must clearly state which equipment is being imported.

Step 3: Prepare Technical Documents

Prepare the site plan, tank layout, piping details and other engineering documents as required for the installation. Application drawings, equipment drawings and installation must match.

Step 4: Preparing and Submitting the Application

Select the appropriate PESO application form and gather the technical documentation needed. Double check applicant information, manufacturer details, equipment name, capacity, drawing number, and location before submission.

Step 5: Answering Questions

There may be questions raised by PESO where there are issues with the information being submitted. It is important to clearly identify the changes made in answering the question and make sure all associated documents have been updated accordingly.

Step 6: Inspection and Approval

When required, there may be an inspection or verification of the installation or equipment. Once all requirements have been fulfilled, the appropriate certificate or license will be issued based on its terms.

---

Common Documentation Problems in Naphtha Storage Applications

In practice, however, the challenge of compliance work does not lie in locating documentation but in ensuring that the documentation matches itself.

Tank Drawing and Site Layout Do Not Match

What might appear in the tank drawing can be different from what appears in the site layout That will appear trivial at the procurement stage but become a technical inconsistency in the context of regulatory review.

Name of Manufacturer Mismatched Across Documents

A foreign supplier can use one name of the group company for the catalogue and another for the test certificate The application must spell out the connection where necessary.

Generic Test Certificates

The generic test certificate does not adequately prove the compliance of the particular unit being imported The model number needs to be traceable.

Inadequate Technical Drawings

Technical drawings of the tank alone will not provide adequate information for a comprehensive installation assessment Relevant connections, piping, valves, safety aspects, etc. must be included.

Starting the Compliance Process After Shipment

This is perhaps one of the costlier mistakes Once the equipment has been shipped to India, if some design issue crops up, modification will involve coordinating with the foreign manufacturer, custom clearance, etc. at an extra cost For imported jobs, compliance must begin before procurement has been finalized, not after shipment.

---

Does Imported Naphtha Equipment Need PESO Approval?

It depends on what is being imported and how that equipment will be used.

PESO’s FAQ specifically addresses imported electrical equipment for hazardous applications and states that approval requires manufacturer information, Indian-agent information, technical descriptions, drawings where applicable, and certification from IEC or EN accredited test houses, among other documents.

It also states that approval is issued to the manufacturer or, in the case of a foreign manufacturer, its Indian agent; users are not given such equipment approvals Therefore, an importer should identify whether the imported package includes separately regulated equipment For example, hazardous-area electrical equipment can require a different compliance assessment from the petroleum storage licence itself and This is why calling the entire project simply “tank approval” can be misleading.

---

Naphtha Storage Equipment Import: A Practical Compliance Checklist

Before placing the final purchase order, an importer should ideally have the following information available:

Product

• Naphtha specification
• Flash point information
• Safety data sheet
• Intended use
• Storage quantity

Equipment

• Tank specifications
• Capacity
• Design drawings
• Material details
• Manufacturer details
• Technical datasheets
• Valves and fittings
• Pumps
• Instrumentation
• Electrical equipment

Installation

• Site layout
• Tank arrangement
• Transfer lines
• Piping and instrumentation
• Safety systems
• Fire protection
• Drainage
• Access arrangements
• Hazardous-area information

Regulatory

• Applicable Petroleum Rules requirements
• Appropriate application form
• Manufacturer authorisation
• Indian agent information, where applicable
• Certificates and test reports
• Inspection requirements
• Approval conditions

The exact checklist should be finalised after assessing the proposed installation rather than copied from another petroleum project.

---

What Does PESO Approval for Naphtha Storage Cost?

There is no responsible single price that applies to every naphtha storage project.

The cost depends on factors such as:

• Storage capacity
• Number and type of tanks
• Nature of imported equipment
• Whether equipment-specific approval is involved
• Site configuration
• Applicable licence
• Inspection requirements
• Drawing and engineering scope
• Number of products or models
• Documentation condition

Government fees and professional consultancy charges should therefore be considered separately For an accurate estimate, the importer should first provide the equipment list, storage capacity, product details and proposed installation information.

---

How Long Does the PESO Process Take?

The timeline varies according to the approval category, technical complexity, completeness of documents, inspection requirements and the time taken to respond to regulatory queries.

PESO publishes an SOP covering approvals and licences under the Petroleum Rules, 2002 Rather than relying on an advertised fixed number of days, an importer should plan the project around document readiness and regulatory dependencies A technically complete application can move more predictably than one that requires repeated corrections.

---

Which Authority Handles Naphtha Storage Approval?

The Petroleum and Explosives Safety Organisation (PESO) is the main central organisation that regulates the petroleum safety scheme discussed above.

PESO comes under the Department for Promotion of Industry and Internal Trade, Ministry of Commerce and Industry, Government of India The relevant legislative provisions include the Petroleum Act, 1934 and the Petroleum Rules, 2002 One must consider the official website of PESO as one’s first port of call for any up-to-date forms and procedures.

---

How Diligence Certification Can Help With PESO Approval

For companies manufacturing and importing petroleum products, the role of a compliance consultant goes beyond uploading documents The important part comes prior to the upload.

Diligence Certification can prepare the process according to the following steps:

• Applicability Assessment
• Proper identification of PESO route
• Preparation of Document Checklist
• Reviewing technical documents
• Coordination of equipment specifications
• Drawing coordination
• Preparation of Application
• Filing Assistance
• Coordination of query responses
• Inspection assistance if required
• Follow up for approval

As far as storage of petroleum products is concerned, Diligence offers consultation in connection with documents, drawings, technical data etc The advantage of this is clear, as the application will be prepared based on the actual project and not vice versa.

---

Conclusion

The submission for PESO approval for the Storage of Naphtha should ideally be part of the process of procurement and installation of the equipment, rather than an administrative procedure that can come in later on.

In the case of petroleum manufacturers and importers, the major concern is often that of documentation mismatch. The equipment could be perfect but if there is any mismatch between the manufacturer’s certification, model number, drawings, layout and the application, then the process will inevitably encounter unnecessary delays Naphtha has been specifically mentioned by PESO as one of the petroleum products for which a storage license is required.

For those looking to import naphtha storage equipment to India, the first step would be to look at the classification of the product, the scope of the equipment, technical drawings and layout for the storage. Based on all of this, the right PESO procedure can be chosen For help with documentation, application processing and regulatory compliance, you can contact Diligence Certification.

---

Frequently Asked Questions
